Thermal Circuit Breakers, 35A 12V/24V Automatic Reset Breaker Protection Pack of 2 for Systems(40a)

Product DescriptionTechnical dataCurrent rating range 3-50AInput voltage rating 12/24VDC:14/28VDCcompliances SAE J553.Contact Endurance 125vac X150% of rated current >500 cycles125vac X200% of rated current >200 cycles.Insulation Resistance >100MOHM(DC 500VDielectric Strength >1500VAC/min.Breakering Capacity 4 times rated current'Automotive Type Auto-reset: 12/24VDC Automotive Type I Automotive Type Modified- Reset: 12VDC Automotive Type IIAutomotive Type Manual- Reset: 12VDC Automotive Type IllMaterials UL 94V-0 Thermoplastic body, thermoset for Type Ill buttonsMechanical/Environmental Data.Operating Ambient Temperature: -10to +60Storage Temperature Rating:40°Cto+100°CTerminal Type: #10-32 thread and 0.25 quick-connect options availableTypical applicationsTrolling motors, Battery chargers, trucks, buses, RV'SFor Plastic CoverCalibration(at25)100 % of Rated Current: Hold, No Trip150% of Rated Currentrip Within 1 Hour.200% of Rated Current: 4.0-40.0 SEC Trip300% of Rated Current1.2-12.0 SEC Trilp==========Type : Moulded CaseModel Number : AR-45AIs Smarts Device : NoOrigin : Mainland ChinaCurrent rating range : 3~50AInput voltage rating : 12/24 VDC; 14/28VDCInsulation Resistance : >100MOHM (DC 500V)Dielectric Strength : > 1,500VAC/min.Breakering Capacity : 4 times rated current

• APPLICATION:Circuit overload protectors switch can play the role of over current protection and short circuit protection, protecting the power circuit from overheating due to overload.
• FEATURE:and wear-resistant, ensuring long service life, reliable use.
• Good insulation, heat resistance, melting resistance and good conductivity, which can maintain stable current connection and excellent thermal sensor.
• CIRCUIT PROTECTION: Compact design enables high density circuit protection configuration. Made of durable plastic, and long service life.
• Widely used for overload and short circuit protection.
