SVAAR 0 Gauge 1 Gauge 2 Gauge Tinned Copper Wire Lugs with 5/16" and 3/8" Stud Ring Terminals Battery Copper Cable Lugs Battery Terminal Connectors Heavy Duty Crimp Cable Ends with Heat Shrink Tube
Product details
| Management number | 215620782 | Release Date | 2026/04/12 | List Price | $12.40 | Model Number | 215620782 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
- Tinned Copper - Cable lugs are made of T2 low resistivity copper, purple copper with strong durability ,99.9% purple copper structure achieved excellent conductivity,With special matte tinned process, their less Impurities and provide you a higher degree of conductivity and more corrosion resistance.
- Safer Closed-end Designed - These copper ring terminals Conform to UL486 standard,have a closed end designed,that makes it possible for cables to stay dry and corrosion free.can be connected by crimping and soldering.And Come with 3:1 dual wall adhesive heat shrink tubings,good insulation and sealing effect to keep the cable dry and extend the service life.And also used to distinguish positive and negative electrodes.
- Widely Application - Used for 1/0 AWG 1 AWG 2 AWG Cable,Stud size:3/8 inch and 5/16 inch.Wire lugs Suitable for use in inverters,distribution box, marine, golf carts, solar panels, home applications, etc. The Uncut heat shrink sleeve in long tubes, which can be cut and used at desired length.
- Reliable - These ring terminals have a close end pad design,Flared opening for easy wire insertion. Size is stamped on pad, easy to identify. keeping electrical components, batteries and cables safe and free from moisture, and also prevents solder from leaking during installation
- Freedom Choose Variety Sizes - Freedom to choose from a variety of wire sizes, stud sizes & pack quantities, that fit your requirements and applications; Can be crimped or soldered; Use with a compatible copper cable; Audio wire may not be a direct fit. Recommend to check product dimensions to ensure a proper fit.
| Color | Tinned Copper |
|---|---|
| Terminal | Ring Terminal |
| Stud Size | 5/16" and 3/8"Stud |
| Brand Name | SVAAR |
| Unit Count | 1.0 Count |
| Manufacturer | SVAAR |
| Material Type | 99.9% Purple Copper, Copper, Cu-ETP/C11000 Purple Copper(Red Copper), Tinned Copper |
| Connector Type | Crimp/Solder Copper Lugs, Heavy Duty Crimp Copper Tube Lugs, Ring |
| Maximum Voltage | 12 Volts (DC) |
| Contact Material | Cu-etp/C11000 Purple Copper(red Copper),tinned Copper |
| Specification Met | UL |
| Temperature Rating | Up to 300 F |
| Insulation Material Type | Non-Insulated |
