SpecialTouch 32 Inch Infrared IR Touch Screen Panel - USB Interface
Product details
| Management number | 219299634 | Release Date | 2026/05/03 | List Price | $73.15 | Model Number | 219299634 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
SPECIFICATION Standard Size: 32 inch Ratio: 16:9 Number of Touch Points: 20 Minimum Touch Object: 2mm Touch Activation Force: No minimum touch pressure required Touch Durability: Unlimited Durability Resolution: 32768*32768 Linearity Deviation: ±1mm Frames per Second: Up to 450 fps Typical Response Time: 3-10ms Light Transmission: 100% without glass Operating Systems: Driver free for Windows7, Windows8, Windows10, Native Linux, Native Android (Compatible with GreenTouch Android Box). Single point under Mac (Does not support Smart TV Android system, Raspberry Pi) Protocols: HID,TUIO,Flash Re-development Provide: free SDK, support C/C++, C#, Java etc. Noise : No Noises Lift Time : 7 -10 years ELECTRICAL Power Supply: Single USB Connection Low Power Consumption: Operating ≤2W, Stand By ≤ 250mW ESD: Contact Discharge 8kV,Air Discharge 15kV,15kV on USB connector pins ENVIRONMENT Operating Temperature: -20°C~70°C Storage Temperature: -40°C~85°C Operating Humidity: 10%~90%RH(Non-condensing) Storage Humidity: 10%~90%RH Certification: FCC,CE,ROHS Warranty: 1 year Note : If there is any other question , please feel free to contact us !
- High Quality Material: With aluminum alloy black frame, it has a long service life. No blind spots, breakpoints, jumps, pauses and other undesirable phenomena. Fast response time 10ms.
- Lightfast Design: The IR touch frame can be applied to internal and external link environments, And is widely used in touch all-in-one machines, touch kiosks, touch digital signage.
- Easy to Install: Our ir touch screen overlays are plug-in design, The installation work is very easy. If the touch positioning is not accurate after installation, We can provide calibration software.
- Scope of Application: USB plug and play, intelligent automatic calibration, driver-free and maintenance-free. Available for Windows, The HID driver needs to be installed in Mac OS.
- Package: Touch frame only (without monitor , without glass)Warranty is 1 year.If there is any other question , Please feel free to contact us
| Brand | SpecialTouch |
|---|---|
| Color | Black |
| Shape | Rectangular |
| Voltage | 5 Volts |
| Model Name | 32 Inch Infrared Touch Frame Overlay Frame Free Driver IR Touch Screen Panel 20 Points Touch HID Compatible |
| Resolution | 32768x32768 |
| Is Electric | Yes |
| Item Weight | 1.18 Kilograms |
| Pixel Pitch | 0.276 |
| Screen Size | 32 Inches |
| Aspect Ratio | 16:9 |
| Display Type | LED |
| Manufacturer | SpecialTouch |
| Refresh Rate | 60 Hz |
| BuiltIn Media | USB Cable |
| Response Time | 10 Milliseconds |
| Screen Finish | Glossy |
| Viewing Angle | 160 Degrees |
| Warranty Type | 1 Year Manufacturer Warranty |
| Contrast Ratio | 2000:1 |
| Processor Count | 1 |
| Total Usb Ports | 2 |
| Has Color Screen | Yes |
| Native Resolution | 32768x32768 |
| Power Consumption | 2 Watts |
| Compatible Devices | Gaming Console, Speaker, Smartphone, Laptop, Desktop, Camera, Tablet |
| Display Technology | just touch frame |
| Total USB 20 Ports | 1 |
| Total USB 30 Ports | 1 |
| Additional Features | Touchscreen |
| Warranty Description | 1 year |
| Hardware Connectivity | Infrared, USB |
| Connectivity Technology | Infrared, USB |
| Item Dimensions D x W x H | 36"D x 22"W x 0.8"H |
| Specific Uses For Product | Business |
| Display Resolution Maximum | 32768*32768 Pixels |
| Total Number of HDMI Ports | 1 |
| Number of Component Outputs | 1 |
| EU Spare Part Availability Duration | 7 Years |
