SMC60A-5 Electronic Control Joystick Leveling Machine, Leveling Instrument Concrete Paver Hall Rocker(5V output 0-5V)

Material: stainless steel + Aluminum alloy Protection: the upper part of the panel IP66 Positioning: spring automatic return Operating Angle: XY axis ±22.5 degrees Operating range: square limit button switch: 1 enable button, 1-6 reset button, waterproof button sensor: Hall sensor Power supply: DC5V, DC12-36V power consumption: less than 32MA (analog voltage signal output, single signal output, 5V power supply) Signal output: analog voltage, USB, RS422, RS232, CAN2.0B, PWM power drive operation life: more than 5 million times; Temperature: -40 degrees ~+70 degrees External dimension: 80X80X238mm External dimension: 61X61mm

• 1. High-Quality Materials: The SMC60A-1 Engineering Machinery Handle Industrial Joystick is made from stainless steel and aluminum alloy, ensuring durability and reliability in industrial environments.
• 2. Superior Protection: With an IP66 rating for the upper part of the panel, this joystick offers excellent protection against dust and water, allowing it to withstand tough working conditions.
• 3. Precise Positioning: Featuring a spring automatic return mechanism, this joystick provides accurate positioning control, allowing for precise movements in the XY axis within ±22.5 degrees.
• 4. Versatile Compatibility: This industrial joystick supports multiple signal outputs, including analog voltage, USB, RS422, RS232, CAN2.0B, and PWM power drive. It can be easily integrated into different systems or machinery.
• 5. Long-lasting Performance: Designed for extended use, this joystick has a minimum operation life of more than 5 million times. It also operates reliably in a wide temperature range from -40 degrees to +70 degrees .
