RAREELECTRICAL 12V Motor Reversing Solenoid Switch Compatible With Cole Hersee 24450 24450Bx Trombetta 214-1211A11 6 Terminal Dpdt Winch Windlass Rv Slide Out Hydraulic Pump

12V Motor Reversing Solenoid Relay Switch Compatible with Cole Hersee 24450 Trombetta 214-1211A11 - 6 Terminal DPDT Winch Windlass RV Slide Out Heavy-duty 12 volt motor reversing solenoid relay switch. DPDT (Double Pole Double Throw) design allows single solenoid to replace multiple solenoids for reversible motor applications. Features dynamic braking for permanent magnet motors when neither coil is energized. Ideal for winches, windlasses, hydraulic pumps, tarp systems, RV levelers, and slide outs. COMPATIBLE APPLICATIONS: Winch Motors - Truck, ATV, UTV, Off-Road Windlass Motors - Boat Anchor Systems Snow Plow & Spreader Motors Hydraulic Pump Motors Tarp Systems - Truck, Trailer RV Levelers - Motorhome, Camper RV Slide Outs - Motor Home, Travel Trailer Boat Lifts - PWC, Pontoon Sea Legs Systems Hoists & Cranes Linear Actuators Other Reversible DC Motors REPLACES OEM PART NUMBERS: Cole Hersee: 24450, 24450BX, 24450-BX, CH24450 Trombetta: 214-1211A11, 214-1231A11, 214-1211A51, 214-1211A61 SPECIFICATIONS: Voltage: 12V DC Type: DPDT Motor Reversing Surge Current: 150 Amps (Inrush) Continuous Current: 75 Amps (5 Minute Carry) Terminals: 6 Total Battery/Motor Studs: (4) 5/16"-24 Threaded Solenoid Operation: (2) 6.4mm (1/4") Blade Terminals Mounting: Flat 180 (F180) Mounting Slots: (2) 7.1mm x 10.4mm Duty Cycle: Intermittent Case Material: ABS Plastic Contact Material: Copper-Cadmium ⚠️ IMPORTANT NOTES: Works ONLY with permanent magnet motors (2 terminal posts) Will NOT work with older copper wound field motors Will NOT work with 3 terminal post winch motors Allow 5 minute cool down after maximum limit use

• Compatible with CAT. Please verify your OEM part number from your original unit to help ensure fitment.
• Replaces: Cole Hersee Part Numbers: / 24450 - Motor Reversing Solenoid / 24450Bx - Motor Reversing Solenoid / 24450-Bx - Motor Reversing Solenoid / Ch24450 - Cole Hersee Oem / 24450-02B - 24V Version (Different Voltage) / Trombetta Part Numbers: / 214-1211A11 - Primary Part Number / 214-1211A11-06 - Revision / 214-1211A51 - Cross-Reference / 214-1211A61 - Cross-Reference / 214-1211A61-06 - Revision / 214-1231A11 - Cross-Reference / 214-1231-A11 -
• Applications: Winch Applications: / Truck Winches - Off-Road Recovery / Atv/Utv Winches - Recreational Vehicles / Trailer Winches - Boat, Utility, Car Hauler / Industrial Winches - Construction, Warehouse / Late Model Ramsey Winches / Late Model Warn Winches / Marine Applications: / Windlass Motors - Anchor Systems / Boat Lifts - Pwc, Pontoon, Boat Dock / Sea Legs Systems - Sea-102 / Boat Trailer Winches / Marine Hydraulic Pumps / Rv & Camper
• Applications: Camper Applications: / Rv Slide Outs - Motor Home, Fifth Wheel / Rv Leveling Systems - Jacks, Stabilizers / Camper Slide Outs - Travel Trailer / Motor Home Accessories / / Snow Plow & Spreader Applications: / Snow Plow Motors - Lift, Angle / Salt Spreader Motors / Sand Spreader Motors / / Truck & Commercial Applications: / Tarp Systems - Dump Truck, Grain Truck, Flatbed / Hydraulic Pump Motors / Hoists - Lift, Crane, Material...
• Solenoid - Voltage: 12V Country Of Origin: CN Duty Cycle: Intermittent Terminal Count: 6 Source: Aftermarket
