Portable Surface Roughness Tester, High Precision Surface Profiler Gauge with Ra Rz Rq Rt Measurement, 0.05-15μm Measuring Range, OLED Display for Metal & Non-Metal Surface Inspection(TR110)

Portable Surface Roughness Tester, High Precision Surface Profiler Gauge with Ra Rz Rq Rt Measurement, 0.05-15μm Measuring Range, OLED Display for Metal & Non-Metal Surface Inspection(TR110)

• High-Precision Professional Tester - This TR100 surface roughness tester is a high-accuracy precision measuring instrument compliant with GB, ISO, DIN, and JIS standards, widely applied to test the surface roughness of various metal and non-metal materials. Its integrated sensor and main body, compact design, make it ideal for flexible on-site measurement in production sites, quality inspection workshops, and manufacturing scenarios.
• Full Measurement Parameters - TR100 Surface roughness tester supports 4 core roughness parameters: Ra, Rz, Rq, Rt, with a measuring range of 0.05~15.0μm for Ra/Rq and 0.1~50μm for Rz/Rt. It delivers a display error of ±(10nm+0.1A) and a repeatability of displayed value less than 6%, and offers 3 optional sampling lengths (0.25mm / 0.8mm / 2.5mm) to adapt to different testing requirements.
• Easy Operation & Fast Measurement - Surface roughness gauge Equipped with a high-brightness 256*64 OLED display for clear and easy data reading, it supports one-key start measurement, and only takes 2 seconds to complete data calculation after the measurement stroke. The one-point calibration function is simple to operate, enabling users to finish calibration quickly; it also supports metric/inch mode switching and 10-minute auto power-off for energy saving.
• Durable Structure - TR100 surface roughness tester adopts a firm and durable piezoelectric ceramic sensor, with a diamond stylus (tip radius 10μm±1μm, 90° tip angle) for accurate and stable testing. The metal shell provides strong anti-interference ability, as well as anti-shock and anti-vibration performance, with a stationary measuring force ≤0.016N to protect both the tested surface and the stylus tip.
• Complete Accessories Kit - Comes with a full set of standard accessories: host device, 5V power adapter, USB cable, operating manual, standard sample template, equipment case, warranty card, qualification certificate and packing list, fully meeting your daily testing and calibration needs.
