Oak M.2 A+E Key 2230 SSD (1T)

The displayed capacity is not equal to the nominal capacity. The capacity of storage products when they leave the factory is usually calculated based on 1MB = 1000KB and 1GB = 1000MB, while the operating system uses a binary algorithm: 1GB = 1024MB. Therefore, there is a certain difference between the displayed capacity and the nominal capacity of the product. So the displayed capacity of flash memory products is approximately 90% of the nominal capacity, which is a normal phenomenon. For example, a nominal capacity of 16GB has an actual capacity of approximately 14.4GB; a nominal capacity of 32GB has an actual capacity of approximately 28.8GB; a nominal capacity of 64GB has an actual capacity of approximately 57.6GB, and so on!

• During the use of the product, please make multiple backups of your important data. In case of product quality issues, the official after-sales service provides replacement of good products, but it does not include data recovery services and does not promise to be responsible for the losses caused by data loss.
• The read and write speeds of flash memory products are influenced by various external factors such as the usage environment (such as card readers, operating systems, motherboard interfaces, etc.), software, and the size of the files being read and written. The speed indicated for our products is based on internal tests conducted by Oak Tree Laboratory and is for reference only.
• The data is sourced from Oak Laboratory. The actual performance may vary depending on the equipment. Oak Solid State Drive Warranty Statement: This product offers a limited warranty. The warranty period is 3 years or the corresponding TBW (Total Bytes Written) write capacity for different capacities, whichever expires first. For example, if the 3-year warranty or the data write capacity exceeds the specified value, both warranty conditions will be considered as having expired, as long as one of them is reached.
• Product dimensions: 30mm (length) x 22mm (width) x 2.6mm (height) Main control model: Lianyun MAP1202 Transmission protocol: PCIe Gen3 x1 Interface type: M.2 A+E Key Flash memory type: 3D TLC/QLC Capacity: 256GB, 512GB, 1TB Maximum sequential read speed: 890MB/S, 890MB/S, 890MB/S Maximum sequential write speed: 850MB/S, 850MB/S, 850MB/S Storage temperature: -40°C to 85°C Operating temperature: 0°C to 70°C Warranty period: 3 years
• M.2 2230 A+E Key interface, widely compatible with M.2 Wi-Fi (PCle signal) 2230-sized slots on laptops, all-in-one computers, desktops and motherboards. The compact and small M.2 A+E Key 2230 specification hard drive provides an additional system storage or system installation disc on your M.2 Wi-Fi slot. The single-sided M.2 2230 (22*30mm) size is suitable for use in mini computers / motherboards / notebook M.2 Wi-Fi slots.
