Measuring Ruler, High Precision 2D Measuring System Adjustable Auto Body Frame Machine Repair Tool For Construction, Machinery Maintenance

Specification:Product Size (With Aluminum Box): 102×20×10cm/ 40.15×7.87×3.9"Material: Aluminum AlloyColor: Blue-BlackMeasuring Range, X Axis: 200mm~2250mm/ 7.87-88.6"Y Axis: 20mm~150mm (Or 340mm)/ 0.8-5.9" OR 13.4"Z Axis: 20mm~150mm (Or 340mm)/ 0.8-5.9" OR 13.4"Package Size: 104×20×10cm/ 41×7.87×3.9"Gross Weight: 3.8kgPacking List:1. Main scale2. 20-150mm scale3. 20-340mm scale4. Screw thread probe5. Magnetic probe6. Magnetic probe and lengthen base7. 3D adapter8. Large positioning probe9. Longitudinal positioning probe10. Small positioning probe11. Size nut probe12. English manualUsage1. When measuring small size within 900mm, no drawing measuring rule is required. Use slide rule according to the position of the ranging point.2. The level (in the level of the level display) shows the measurement. The measurement reading is read on the slider.3. When measuring a size of about 1800 mm, the inner rod that is stretched out and stretched is used, and measured according to the level displayed by the level. The measurement reading is read on the slider holder. Smoothly pull the ruler during the measurement (in the level of the level display).4. The vertical ruler is directly at the measuring point, adjustable up and down, and is screwed to the vertical position to maintain the level (in the level of the level display).Note:1. Please read the instructions before use to ensure that the measuring rule can be used correctly.2. This product is made of aluminum alloy. Please handle with care when using. It is strictly forbidden for heavy objects to touch.3. The magnetic probe of this product is inclined after use. Do not pull it out vertically.

• * Measuring range: X axis: 200mm~2250mm/ 7.87-88.6"; Y axis: 20mm~150mm (or 340mm)/ 0.8-5.9" OR 13.4"; Z axis: 20mm~150mm (or 340mm)/ 0.8-5.9" OR 13.4".
• * High precision, measurement error is less than 1mm.
• * Aluminum alloy material, high strength, small size, light weight, one person can complete measurement independently.
• * It can also be 3D measuring with the adapter connectors.
• * The high-precision measuring ruler is designed and manufactured for the purpose of improving the accuracy and convenience of testing and measurement in the repair of accident vehicles.
