EPEVER Solar Charge Controller 30A 12V 24V Auto PWM Solar Panel Charging Regulator Generator with RS485 Port for Gel Sealed Flooded User Type (LS3024B)

Specifications: Electrical parameters：LS3024B Nominal System Voltage：12V/24V DC auto work Rated Battery Current：30A Maximum PV input voltage：50V Grounding：Common positive Equalize charging voltage：Sealed: 14.6V, Flooded: 14.8V, User-defined: 9~17V Boost charging voltage：Gel: 14.2V, Sealed: 14.4V, Flooded: 14.6V,User-defined: 9~17V Float charging voltage：Gel /Sealed /Flooded: 13.8V, User-defined: 9~17V Low voltage reconnect voltage：Gel /Sealed /Flooded: 12.6V, User-defined: 9~17V Low voltage disconnect voltage：Gel /Sealed /Flooded: 11.1V, User-defined: 9~17V Self-consumption：8.4mA(12V)，7.8mA(24V) Temp. compensation：-3mV/℃/2V（25℃ ref） Working temp.：-35℃~+55℃ Terminal：10mm2 Dimension：200.6x101.3x57mm Net weight：0.5kg Features: Three system voltage configuration : 12V, 24V or 12V/24V auto work ;High efficiency PWM charging with temperature compensation 3 LEDs shows PV charging, battery and load status External temperature sensor interface , RS-485 bus communication Open standard Modbus communication protocol Software update function , More powerful function via MT50 or PC Diversified load control modes : Manual, Light ON/OFF, Light ON+ Timer, Time Control Battery type selection: Gel, sealed, flooded and User type Real-time monitor , Programmable parameters LVD or SOC load disconnect function , Energy statistics function Electronic Protections： PV array short circuit ; Over discharging ;Over charging ; Load overload ;Load short circuit ; PV reverse polarity ;Battery reverse polarity ;Overheating Package : 1X 30Amp PWM solar charge controller LS3024B 1X Manual (English)

• EPEVER PWM solar charge controller 30A 12V/24V auto work , Three LEDs shows PV charging, battery and load status ;Optional RTS for accurate temperature compensation;
• Multiple load working modes: Manual Control, Light ON/OFF, Light On+Timer and Time Control;
• Battery type selection: Sealed, Gel, Flooded and User(programmable);Battery temperature compensation;Real-time energy statistics;
• RS485 port with industrial standard MODBUS open architecture;Real-time data monitoring and parameters setting with MT50, APP or PC software;Support firmware upgrade
• PV short circuit protection ; PV reverse polarity protection ; Battery over voltage protection ; Battery over discharge protection ; Battery reverse polarity protection ; Battery overheating protection ; Load short circuit protection ; Load overload protection ; Controller overheating protection
