Dual Axis Linear Stage 40x60mm | Manual Fine Tune Platform with 0.01mm Accuracy | XZ Sliding Table for Microscopes/Optical Equipment

Item Type: Linear Stage Manual Fine‑Tune PlatformBody Material: Aluminum Alloy (black anodized)Color: BlackModel: HBLX-A60Table Top Size: Approx. 40x60mm/1.6x2.4inProduct Overall Height: Approx. 130mm/5.1inMoving Direction: AZ-axis, 2 directionsMovement Method: Rotating gears and rotating handles to advanceSliding Track: Gear guideRail Type: Dovetail groove typeNumber Of Countertop Threaded Holes: 8pcsThreaded Hole Diameter: Approx. 4mm/0.2inThreaded Hole Depth: Approx. 6mm/0.2inWithstand Load: 49N (5Kgf)Up and Down Movement Stroke: ±20mmMinimum Scale: Approx. 0.01mm/0.0004inMoving Parallelism: 0.05mm/13mmStructure: DetachableApplication: Optical equipment, measuring devices, semiconductor manufacturing equipment, testing machines, microscopes, photographic equipment, handling machines, processing machines, healthcare machines, printing machines and others.How to Use:1. The mechanical sliding table is a general component that completes the feed movement. The complete mechanical sliding table is composed of the sliding table part and its moving common parts, the complete mechanical sliding table part and other moving device brakes and other auxiliary parts. According to the process requirements of the machined parts, a drive unit (with multi-axis box) drilling head, boring head, milling head, boring head, turning head, etc. are installed on it to form various combined machine tools to complete drilling and expansion. , Reaming, scraping end face, chamfering, turning end face, milling, drilling and tapping, etc. Deep hole processing can be completed by configuring a graded feed mechanism on the sliding table (the graded feed mechanism is only used for specifications below HJ32)2. The sliding table can be installed on the side base or column, and can also be installed on the inclined base to form a horizontal, vertical or

• Exact 0.01mm Adjustment - This manual fine-tune platform delivers highly-accurate positioning with a minimum scale of 0.01mm, ensuring meticulous alignment for sensitive optical and measuring equipment. Its dovetail groove guide guarantees smooth movement under 5kg loads.
• Enduring Aluminum Alloy Construction - Excellent aluminum alloy body with black anodic oxidation treatment provides exceptional strength, oxidation protection, and long-term consistency. It withstands friction, drops, and daily use while maintaining lightweight portability.
• User-Friendly Gear Handle Control - Rotating gear handles enable effortless and quiet functioning without loud noises, making it ideal for laboratory and manufacturing environments. The R-angle protection design prevents incidents during use.
• Versatile 8-Thread Hole Design - Features 8 threaded holes (4mm diameter) for flexible mounting of various devices like microscopes, sensors, or cameras. The detachable structure and ±20mm movement stroke adapt to multiple setup configurations.
• Multi-Industry Application Ready - Engineered for optical equipment, semiconductor manufacturing, testing machines, and healthcare devices. This sliding table offers consistent performance in accuracy-demanding tasks, backed by a robust 49N load capacity and stable AZ-axis movement.
