DS51160 160KG RC Servo Motor Waterproof Large High Torque Digital Servos Full Metal Gear 24V for RC Plane Quadcopter Helicopter Robotic Arm (180°)

The 160KG servo motor is ideal for high-load applications such as heavy-duty robotics, large RC models, Industrial Automation, Agricultural or Construction Equipment, Custom Engineering Projects, industrial machinery, and outdoor automation systems. 1. Environmental Conditions Storage Temp. Range: -30℃ to 80℃ Operating Temp. Range: -15℃ to 70℃ Operating Voltage Range: 19.2V to 25.2V 2. Mechanical Specifications Size: 65 × 30 × 48 mm Weight: 175g Gear Ratio: 357 Bearing: Double bearing Connector Wire: 300 ± 5 mm Motor: 3-pole(s) Waterproof: IP67 3. Electrical Specifications Idle Current (at stopped): 4mA@19.2V , 5mA@24V , 6mA@25.2V Operating Speed (at no load): 0.24 s/60°@19.2V , 0.21 s/60°@24V , 0.19 s/60°@25.2V Stall Torque (at locked): 155 kg·cm@19.2V , 170 kg·cm@24V , 185 kg·cm@25.2V Stall Current (at locked): 3.8A@19.2V , 4.2A@24V , 4.5A@25.2V 4. Control Specifications Control System: PWM (Pulse Width Modification) Pulse Width Range: 500 ~ 2500 µsec Neutral Position: 1500 µsec Running Degree: 180° or 270° (when 500 ~ 2500 µsec) Dead Band Width: 3 µsec Operating Frequency: 50 ~ 330 Hz Rotating Direction: Counterclockwise (when 500 ~ 2500 µsec)

• Delivers up to 185 kg·cm stall torque at 25.2V making it good for high-load applications
• Fully waterproof with IP67 rating ideal for outdoor or harsh environments
• Wide voltage compatibility from 19.2V to 25.2V ensures stable performance across different systems
• Compact yet powerful design fits into large RC models without compromising strength
• Good for outdoor automation systems where precision and durability are key under varying temperatures
