CHANCS Geared Reversible Motor 2RPM 8mm Shaft 12V DC Geared Motor for Electric Fan,Beauty Instrument

Specifications: Voltage:DC 12V Reduction ratio:670 Maximum no-load speed:2RPM No-load current:0.06A Rated torque:30kg.cm Rated current:0.25A Rated input power:8W Ultimate load torque:50kg.cm Maximum load current:1A Motor Size: D Shaped Output Shaft Size: 8*16mm (0.31" x 0.63") (D*L) Gearbox Size: 58 x 40 x 27mm (2.28" x 1.57" x 1.06") (L*W*H) Motor Size: 31 x 57mm (1.22" x 2.24") (D*L) Mounting Hole Size: M4 (not included) Main Material: Metal, Electronic component Packages:1 x Worm Gear Motor Attention: 1.The motor must not be overloaded/blocked for use, otherwise it will burn the motor or gear set. 2.The torque of the geared motor is equally determined by the reduction ratio. The higher the reduction ratio, the higher the torque. Applications: automatic mahjong machines, vending machines, medical equipment, ATMs, robots, parking locks, electronic locks, smart home, automation industry, automotive parts, office automation, curtain machines, etc.

• Turbine-worm geared motors are compact and have a self-locking function. when the motor is not energized, the output shaft is fixed and self-locking. The motor can adjust the speed and rotation, the red wire connects to the positive pole, the black wire connects to the negative pole, when the wiring is reversed, the motor steering changes.
• Specifications: Voltage:DC 12V Reduction ratio:670 Maximum no-load speed:2RPM No-load current:0.06A Rated torque:30kg.cm Rated current:0.25A Rated input power:8W Ultimate load torque:50kg.cm Maximum load current:1A DC motor body dimensions:31 x 57mm (1.22" x 2.24") (D*L) Gearbox dimensions:58 x 40 x 27mm (2.28" x 1.57" x 1.06") (L*W*H) Output shaft dimensions:8*16mm (0.31" x 0.63") (D*L)
• The motor adopts metal gears inside, which increases the torque of the motor, is wear-resistant and corrosion-resistant, has good impact resistance, produces low noise, dissipates heat quickly, and has stable output.
• Pure copper coil rotor is made of high quality material, good conductivity, high temperature resistance, low power consumption, strong power, controllable temperature rise, stable speed and long service life.
• Applications: automatic mahjong machines, vending machines, medical equipment, ATMs, robots, parking locks, electronic locks, smart home, automation industry, automotive parts, office automation, curtain machines, etc.
