ATS Camloc Receptacle Drill Jig MS-T16 – Hole-Spacing Jig for 2600/2700 & 4000 Series Camloc Fasteners

The ATS MS-T16 Camloc Drill Jig is a dedicated layout and drilling aid for installing Camloc (C-Lock) style panel fasteners. Designed specifically for Camloc receptacles, this jig ensures that both rivet holes and the center fastener hole are drilled in exactly the right relationship to each other, giving you clean, professional-looking installations every time. Each end of the T-style jig is set up for a different Camloc family: one side has 3/4 inch hole spacing for 2600 and 2700 series fasteners, while the other side provides 1 inch spacing for 4000 series fasteners. That makes the MS-T16 a versatile tool that covers the most commonly used Camloc sizes in aircraft and performance-vehicle work. The jig is machined from lightweight aluminum to reduce fatigue when you’re drilling a long run of receptacles, and it’s fitted with hardened steel bushings so your drill bit tracks straight and the tool holds its accuracy after repeated use.

• Accurate Camloc spacing – Guides drilling so receptacle rivet holes and center hole are positioned correctly for Camloc / C-Lock panel fasteners.
• Two spacing options in one tool – One end of the jig provides 3/4 in. spacing for 2600 & 2700 series Camloc fasteners; the opposite end provides 1 in. spacing for 4000 series.
• Durable construction – Lightweight aluminum body with hardened steel drill bushings for long service life in shop or hangar use.
• Faster, more consistent installs – Speeds up layout and drilling when adding or replacing Camloc receptacles on cowlings, inspection panels, fairings and other sheet-metal assemblies.
• Made for aviation & motorsports fabrication – Ideal for aircraft builders, A&P mechanics, and race-car fabricators working with quick-release Camloc fastener systems, which lock and unlock with a simple quarter-turn action.
