12V 2CH Flip-Flop Bistable Self-Locking Relay Module Trigger Switch Board (4)

Product Name:12V 2CH Flip-Flop Bistable Self-locking Relay Module Trigger Switch BoardPacking list:2 Channel DC 12V Bistable Self-locking Relay ModuleDescription:2 Channel DC 12V Self-locking Relay Module(version 3) :Working voltage: DC 12VWorking current: 1 relay 70MA;2 relay 140MA;Standby current: 0.2mALoad current: AC 250V / 10A, DC 30V / 10ATrigger mode: Low pulse triggerSize: 36mm * 32.3mm * 18.5mm (L * W * H)Weight: 24.5 gUSE 1:By default, the relay is release, press the trigger button, the relay pull, press again, the relay release, the third press, the relay pull, and so on.USE 2:By default, the relay is release, MCU output low-pulse(0.3-1seconds), the relay pull, low-pulse again, the relay release, the third low-pulse, the relay pull, and so on.Module interface:1. V: positive power supply (VCC)2. G: negative power supply (GND)3. T (T1/T2/T3/T4): Low pulse triggerRelay outputs:1. NO: normally open relay interface2. COM: Common Interface Relays3. NC: normally closed relay interfaceUSE : By default, the relay is release, press the trigger button, the relay pull, press again, the relay release, the third press, the relay pull, and so onTypical applications:Automotive electronicsMotor/PLC/LEDSmart Home/Home automationEmergency lightingMCU development boardToy carfor UNO MEGA2560 raspberry pi diy electronic kit

• 2 Channel DC 12V Bistable Self-locking Relay Module
• Working voltage: DC 12V
• Standby current: 0.2mA
• Trigger mode: Low pulse trigger
• Load current: AC 250V / 10A, DC 30V / 10A
